Magnet crane with rotating trolley  is a special product equipped with electromagnetic chuck that used to lift iron or steel blocks, cylinders and so on. It

consists of bridge, crane traveling mechanism, trolley, electric equipment and electromagnetic chuck. Both traveling mechanism and trolley motors are

special motors for canes, large starting torque and loading capacity. Magnetic retentive is 10 minutes after power shut. The shape of electromagnet can

be designed according to adsorptive goods

magnetic crane, magnet lift crane, magnet crane, double girder magnet crane, crane with magnet

Specifications :

LiftingCapacity : from3 T to50t

Span: 4.5m to 37.5m

Lift height: 3m to 30 m

Working duty:  A6(M6), A7(M7).

CE, TUV, GOST certificate, Top quality

Technical Parameters:

Technical Data(carrier-beam and girder  vertical or  paralleled )

Capactiy(t)

Span (m)

Lifting Height   (m)

Work Duty

 Lifting Speed   (m/min)

Crab Travelling Speed   (m/min)

Trolley Travelling Speed   (m/min)

Total Power (kw)

Rail

15

22.5~34.5

16

A6

13.2

36.7

101.4

63

43kg/m   or   QU70

A7

15.8

36.6

103.9

79.5

20

22.5~34.5

16

A6

12.6

36.2

89

71

15

A7

15.8

42.8

103.9

94.5

32

22.5~34.5

15

A6

12.5

37

87.3

111.3

QU70

16

A7

15.1

43.3

104.3

135.5

QU80

40

22.5~34.5

16

A6

11.7

37.5

87.3

128.5

QU100

A7

15.3

43.2

113.9

173

Technical Data(Rotation of the Carrier-beam)

Capactiy(t)

Span (m)

Lifting Height   (m)

Work Duty

 Lifting Speed   (m/min)

Rotation Speed (r/min)

Crab Travelling Speed   (m/min)

Trolley Travelling Speed   (m/min)

Total Power (kw)

Rail

20

19.5~34.5

16

A6

13.4

1.2

37

87.3

113.5

QU80

A7

14.7

43

104.3

122.7

25

19.5~34.5

16

A6

11.8

1.2

37

87.3

114.3

A7

14.7

43

104.3

122.7

32

19.5~34.5

16

A6

10.6

1.3

38.5

103.8

148

A7

13.4

43.1

113.9

178.5

40

19.5~34.5

16

A6

10.5

1.3

37.5

103.8

170

A7

13.4

43.1

106.4

205.5

QU100

Technical Data(Rotation of the Crab)

Capactiy(t)

Span (m)

Lifting Height   (m)

Work Duty

 Lifting Speed   (m/min)

Rotation Speed    (r/min)

Crab Travelling Speed   (m/min)

Trolley Travelling    Speed   (m/min)

Total Power    (kw)

Rail

20

19.5~34.5

16

A6

13.4

1.6

37

87.3

95.3

QU80

A7

15.8

43

104.3

112.5

32

19.5~34.5

16

A6

12.8

1.64

32

90.8

134.3

A7

15

43

106.4

159.3

40

19.5~34.5

16

A6

12

1.56

33.5

90.8

149.3

A7

15

1.64

43

106.4

183.3



working conditions:

1. Working temperature: -25-+45 degree

2. Work moisture: <85%

3. Flammable, explosive and corrosive gas are forbidden in the work environment, there will be special used crane for these environment.

Common configuration:

1.control methods: Pendant control or remote control, Or Driver's cabin control.

2. drive units: motor+gear box+brake

3. safety device: overload limit, travel limit, over speed limted, etc.

4. Shrouded DSL system for trolley power feeding

5. Electric control box: standard is CHINT electric,  Schneider-electric is for choose .

Features & Advantages:

1. Reasonable structure, light dead weight

2. Favorable performance, accurate and smooth lifting.

3. Safe and reliable traveling

4. Low noise, easy operation,

5. Convenient maintenance, high exchange ability for parts and components

6. Main girder: box-shaped girder
